Circuit Description

These DTCs are output when the driver door power window regulator motor circuit is malfunctioning.

Fig 1: Jam Protection Limit/Pulse Switch Circuit On Driver Door Circuit Description
G02956626Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
