Front Stabilizer Bar: Removal

Remove the 2 nuts, 2 bolts, 4 retainers, 4 cushions and 2 stabilizer bar links.

Torque:

Bolt: 52 N.m (530 kgf.cm, 38 ft.lbf)

Nut: 25 N.m (250 kgf.cm, 18 ft.lbf)

Fig 1: Identifying Stabilizer Bar Link Nuts

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

1. Remove the 4 bolts, 2 brackets and 2 cushions.

   Torque: 18 N.m (185 kgf.cm, 13 ft.lbf)

2. Remove the stabilizer bar.

Fig 2: Identifying Bolts For Stabilizer Bar

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
