Diagnostic Trouble Code Chart

WARNING: This page is about a different car, the 2004 Toyota Sienna. However, it is still accessible from the selected car via links, so may be relevant.

NOTE:

If no abnormality is found when the parts are inspected, inspect the skid control ECU.
When a malfunction is found in the skid control ECU, replace the brake actuator assy.
If a malfunction code is displayed during the DTC check, check the circuit listed for that code. For details of each code, refer to the "See page" under respective "DTC No." in the DTC chart.
DTC 13 will not be output, if the check is Performed by the hand-held tester.

Fig 1: Tire Pressure Warning System DTC Chart
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
