O2S Test Result

Refer to O2S TEST RESULT  for detailed information.

Rear HO2S voltage:

Fig 1: Test Result (Rear HO2S Voltage)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Rear HO2S response:

Fig 2: Test Result (Rear HO2S Response)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Rear HO2S element:

Fig 3: Test Result (Rear HO2S Element)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
