Circuit Description

These DTCs are output when the driver's door power window regulator motor circuit is malfunctioning.

Fig 1: Jam Protection Limit Switch\Pulse Sensor Circuit On Driver Side Door - Circuit Description Chart
G01442922Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
