Inspect Fuel Tank And Line

Check the fuel lines for cracks or leakage, and all connections for deformation.
Check the fuel tank vapor vent system hoses and connections for looseness, sharp bends or damage.
Check the fuel tank for deformation, cracks, fuel leakage or tank band looseness.
Check the filler neck for damage or fuel leakage.

Fig 1: Inspecting Fuel Line (1 Of 2)
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 2: Inspecting Fuel Line (2 Of 2)
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Hose and pipe connections are as shown in Fig 3 .

Fig 3: Identifying Dimensions Of Hose & Pipe Connections
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

If a problem is found, repair or replace the parts as necessary.
