Compressor And Magnetic Clutch: Reassembly

WARNING: This page is about a different car, the 2003 Lexus LS 430. However, it is still accessible from the selected car via links, so may be relevant.

INSTALL STATOR
1. Install the stator.

  Fig 1: Installing Stator
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
2. Install the snap ring.

  Fig 2: Installing Snap Ring
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

  NOTE: The snap ring should be installed so that its beveled side faces up.

  Fig 3: Instructions For Snap Ring Installation
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
3. Connect the connector to the stator.

  Fig 4: Connecting Stator Connector
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
INSTALL ROTOR
1. Install the rotor.
2. Install the snap ring.

  Fig 5: Installing Snap Ring
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
NOTE: The snap ring should be installed so that beveled side faces up.

Fig 6: Instructions For Snap Ring Installation
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
INSTALL PRESSURE PLATE
1. Install the shims to the pressure plate and install the pressure plate on the rotor.

  Fig 7: Installing Shims To Pressure Plate
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
2. Using SST and a torque wrench, install the shaft bolt.
  SST 07112-66040, 07112-76060

  Torque: 13.2 N.m (135 kgf.cm, 9 ft.lbf)

  Fig 8: Installing Shaft Bolt
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
INSPECT MAGNETIC CLUTCH CLEARANCE
1. Set the dial indicator to the pressure plate of the magnetic clutch.
2. Connect the magnetic clutch lead wire to the positive (+) terminal of the battery.
3. Check the clearance between the pressure plate and rotor when connecting the negative (-) terminal to the battery.

  Fig 9: Checking Magnetic Clutch Clearance
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Standard Clearance:

0.30-0.55 mm (0.012 +/- 0.022 in.)

If the clearance is not within the standard clearance, adjust the clearance using shims to obtain the standard clearance.

Shim Thickness:

0.1 mm (0.004 in.)

0.3 mm (0.012 in.)

0.5 mm (0.020 in.)
