Diagnosis & Repair

For wiring diagram, see Fig 1. For diagnosis and repair, see Fig 2.

Fig 1: Throttle Actuator Control Motor Current Wiring Diagram

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 2: Diagnosis & Repair Of Throttle Actuator Control Motor Current

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
