Diagnostic Trouble Code Definitions
>>
DTC C1246
>>
Circuit Description
Circuit Description
For circuit description, see
Fig 1
.
Fig 1: Circuit Description Master Cylinder Pressure Sensor
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
