Intake Air Control Valve ASSY No. 2 (1MZ-FE/3MZ-FE): Replacement

WARNING: This page is about a different car, the 2004 Toyota Camry. However, it is still accessible from the selected car via links, so may be relevant.

REMOVE INTAKE AIR CONTROL VALVE ASSY NO. 2
1. Remove the 3 bolts and nut.
2. Rotate the lever to the closed position as shown in the illustration and pull out the IAC valve.
3. Remove the gasket from the intake air surge tank.

  Fig 1: Removing Intake Air Control Valve Assy No. 2
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
INSTALL INTAKE AIR CONTROL VALVE ASSY NO. 2
1. Install a new gasket to the intake air surge tank.
2. Install the IAC valve with the 3 bolts and nut.
  Torque: 10 N.m (102 kgf.cm, 7 ft.lbf)
