System Check
WARNING:
- The key in the control panel must be turned to the 'Off/Check' position prior to any maintenance or repair procedures being performed on the fire suppression system. Failure to do this could cause the system to activate.
- A system check must be performed weekly.
Battery condition check:
Fire suppression control module panel - battery check switch
NOTE:
Make sure that the key switch on the control box is in the OFF/CHECK position, before testing battery condition.
To check battery condition, press and hold the red BATTERY CHECK switch on the control module's panel.
The following LED responses can be seen:
- Flashing yellow light - indicates that the batteries are in a good state of charge.
- Weak yellow light - indicates that the batteries are low in charge, replace the batteries.
- If in doubt, replace the batteries.
