Component Locations
COMPONENT LOCATIONS
| Component | Location |
|---|---|
| Front Wiper/Washer Switch | Top Of Steering Column |
| Front Wiper Motor | Left Side Of Bulkhead |
| Front Wiper Relay | Inside Center Console |
| Rear Washer Switch | Top Left Side Of Instrument Panel, Near Instrument Cluster |
| Rear Wiper Switch | Top Left Side Of Instrument Panel, Near Instrument Cluster |
| Rear Wiper Motor | Right Side Of Tailgate |
| Rear Wiper Relay | Behind Left Footwell Trim Panel |
| Washer Pumps | On Washer Fluid Reservoir |
| Washer Fluid Reservoir | Right Rear Corner Of Engine Compartment |
