IGNITION TIMING

TECHNICAL SERVICE BULLETIN

Reference Number(s): 86/07/94/US, Date of Issue: September 02, 1994

LAND ROVER:	Range Rover, Discovery
SECTION:	Electrical
AFFECTED VEHICLES:	Range Rover from LH 647645, Discovery from LJ 081991

DETAIL

A small number of reports have been received which indicate that ignition timing has been set incorrectly at the point of manufacture from the above VIN numbers.

It is possible that this condition may be due to a parallax effect caused by the angle at which the timing marks are viewed. To ensure that any confusion is alleviated the correct way to view the timing marks is from the left side of the engine looking beneath the power steering pump towards the torsional vibration damper (shown by the arrows in Fig 1 ).

ACTION REQUIRED

Upon customer complaint of poor engine running and at 30,000 mile service intervals check the ignition timing as described in the workshop manual.

PARTS INFORMATION

Not applicable

PROCEDURE

Follow the procedure in section 86 - adjustment-ignition timing, viewing the timing marks as shown in Fig 1 .

Fig 1: Locating Timing Marks

WARRANTY

Normal warranty policy and procedures apply.

COMP. CODE:
1. 7A1

SRO:
1. 86.35.15 - 00.40 hour
  NOTE: Not to be submitted under Warranty when performed in conjunction with the 30,000 mile service.
