Repair Procedures: Replacement

WARNING: This page is about a different car, the 2024 Kia K5. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the front door trim.

    (Refer to " Replacement  ")

  2. Loosen the mounting screws and remove the front door inside handle (A).
    G13835380Courtesy of KIA MOTORS AMERICA, INC.

    Information

    Be careful of breakage and cut the heat-welded part with a knife.

  3. Install in the reverse order of removal.
    NOTE:
    • Make sure the door locks/unlocks and opens/closes properly.
    • Replace any damaged clips (or pin-type retainers).
