Description And Operation: Description
The heated steering wheel system improves the thermal comfort of the driver by heating the steering wheel when manually selected.
 Courtesy of KIA MOTORS AMERICA, INC.
|
 Courtesy of KIA MOTORS AMERICA, INC.
|
VOLTAGE SPECIFICATION
| Item |
Specification |
| Voltage |
13.5 V |
| Heated pad resistance |
1.7 Ω ± 10% |
| NTC resistance |
10.0 kΩ ± 5% [25°C (77°F)] |
