Home >> Kia >> 2021 >> Telluride SX, FWD >> Repair and Diagnosis >> Accessories & Equipment >> Drivers Assistance Systems - ADAS >> Rear View Monitor (RVM) >> Repair Procedures >> Removal

Repair Procedures: Removal

  1. Remove the liftgate garnish.

    (Refer to Body - "LIFTGATE GARNISH ")

  2. Remove the rear view camera (A) by loosening the screws.
    G13313017Courtesy of KIA MOTORS AMERICA, INC.
