| 1 |
Rear door left speaker (+) |
- |
| 2 |
Rear door left speaker (-) |
Mic (+) |
| 3 |
USB Ground |
- |
| 4 |
USB Data (High) |
- (Detent) |
| 5 |
USB Data (Low) |
Remote antenna |
| 6 |
USB VCC |
Illumination (+) |
| 7 |
Rear camera video |
Multmedia-CAN (High) |
| 8 |
- |
- |
| 9 |
- |
- |
| 10 |
AUX Audio right_input |
Battery (+) |
| 11 |
AUX Detect |
Battery (+) |
| 12 |
- (Steering wheel key) |
Ground |
| 13 |
Front door left speaker (+) |
Ground |
| 14 |
Front door left speaker (-) |
- |
| 15 |
Front door right speaker (-) |
Mic (-) |
| 16 |
Front door right speaker (+) |
- |
| 17 |
- |
- |
| 18 |
- |
Vehicle Speed |
| 19 |
- |
Illumination (-) |
| 20 |
Rear camera power |
Multmedia-CAN (Low) |
| 21 |
Rear camera video_ground |
- |
| 22 |
- |
ACC |
| 23 |
- |
- |
| 24 |
AUX Audio left_input |
- |
| 25 |
AUX Audio ground |
- |
| 26 |
- (Steering wheel key_ground) |
- (Door open) |
| 27 |
Rear door right speaker (-) |
- |
| 28 |
Rear door right speaker (+) |
- (Parking brake) |
| 29 |
- |
- (P-Position) |
| 30 |
- |
- (Auto light) |
| 31 |
- |
- |
| 32 |
Rear camera ground |
IGN1 |
| 33 |
- |
- |
| 34 |
- |
- |
| 35 |
- |
- |
| 36 |
Rear camera detect |
|
| 37 |
- |
| 38 |
- |
