Special Service Tools: Notes

Tool Name/Number	Illustration	Description
Engine support fixture (bar) 09200-3N000	Courtesy of KIA MOTORS AMERICA, INC.	Used for holding engine assembly when removing/installing transaxle Used with the adapter (09200-4X000) and supporter (09200-2S000) * Refer to the engine support fixture assembly drawing below.
Engine support fixture assembly 09200-2S000 Engine support fixture 09200-2S100 09200-2S200	Courtesy of KIA MOTORS AMERICA, INC.	Used for holding engine assembly when removing/installing transaxle Used with the bar (09200-3N000) and adapter (09200-4X000) * Refer to the engine support fixture assembly drawing below.
Engine support fixture (adapter) 09200-4X000	Courtesy of KIA MOTORS AMERICA, INC.	Used for holding engine assembly when removing/installing transaxle Used with the bar (09200-3N000) and supporter (09200-2S000) * Refer to the engine support fixture assembly drawing below.
Oil seal installer 09452-26100	Courtesy of KIA MOTORS AMERICA, INC.	Installation of transaxle case oil seal. Used with the handle (09231-H1100)
Handle 09231-H1100	Courtesy of KIA MOTORS AMERICA, INC.	Installation of transaxle case oil seal. Used with the installer (09452-26100)
Position switch guide pin 09480-A3800	Courtesy of KIA MOTORS AMERICA, INC.	Used for fixing "N" range when installing inhibitor switch
