Repair Procedures: Replacement
WARNING: This page is about a different variant/trim than selected.
Information
CAUTION:
Be careful as the Liftgate may fall down on people when the lifts are removed. Have a helper hold the Liftgate open, or use a secure method to hold it open.
- Using a screwdriver (A), lift up slightly the socket clips (B) of both ends on the lifter (D), and then remove the lifter from the bracket (C).
 Courtesy of KIA MOTORS AMERICA, INC.
|
- Push the socket of the lifter into the bracket for installation.
Information
CAUTION:
Make sure the Liftgate locks and opens properly and locks securely.
