Repair Procedures: Disposal

WARNING: This page is about a different variant/trim than selected.
  1. Fully extend the piston rod.
  2. Drill a hole on the A section to remove gas from the cylinder.
Fig 1: Checking Section Hole Drilling Area
G12141422Courtesy of KIA MOTORS AMERICA, INC.
