Charging System: Alternator
WARNING: This page is about a different variant/trim than selected.
ALTERNATOR SPECIFICATIONS
| Item | Specification |
|---|---|
| Rated voltage | 13.5V, 150A |
| Speed in use | 1, 500 - 18, 000 RPM |
| Pin | 3 (C, L, FR) |
| Pulley Type | General pulley |
| Voltage regulator | IC Regulator built in type |
| Default regulated voltage (V) [COM terminal] | 14.39 - 15.43 [-35°C(31°F)] |
| 14.15 - 14.95 [25°C(77°F)] | |
| 13.23 - 14.49 [140°C(284°F)] | |
| Regulator Setting Voltage (V) [COM terminal] | 11.0 - 16.0 [5, 000 rpm/min/10A] |
