Engine Control System Diagnosis - 2.4L (1 Of 3) (Except HEV)
>>
DTC P0193-00: Fuel Rail Pressure Sensor Circuit High Input
>>
Specification
>>
Signal Waveform & Data
Signal Waveform & Data
Fig 1: Scantool Display - Fuel Rail Pressure Sensor Signal Voltage Increases In Proportion To Engine Speed (Engine Load)
Courtesy of KIA MOTORS AMERICA, INC.
Courtesy of KIA MOTORS AMERICA, INC.
