Terminal and Connector Inspection
- Many malfunctions in the electrical system are caused by poor harness and terminals.
Faults can also be caused by interference from other electrical systems, and mechanical or chemical damage.
- Thoroughly check all connectors (and connections) for looseness, bending, corrosion, contamination, deterioration, and/or damage.
- Has a problem been found?
YES
- Repair as necessary and then go to "Verification of Vehicle Repair " procedure.
NO
- Go to "Ground Circuit Inspection " procedure.
