WARNING: This page is about a different car, the 2018 Kia Forte5 and 2018 Kia Forte. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Multi-Media Jack Troubleshooting Flow Chart 4 (1 Of 4)
Courtesy of KIA MOTORS AMERICA, INC.
Fig 2: Multi-Media Jack Troubleshooting Flow Chart 4 (2 Of 4)
Courtesy of KIA MOTORS AMERICA, INC.
Fig 3: Multi-Media Jack Troubleshooting Flow Chart 4 (3 Of 4)
Courtesy of KIA MOTORS AMERICA, INC.
Fig 4: Multi-Media Jack Troubleshooting Flow Chart 4 (4 Of 4)
