G-Sensor Calibration

  1. Ignition "OFF", connect GDS.
  2. Ignition "ON" & Engine "OFF" select vehicle name and ESP system.
  3. Perform G-sensor calibration.
  4. Perform the "G-Sensor Calibration" procedure with GDS.
    Fig 1: Display - G-Sensor Calibration Screen
    G09766296Courtesy of KIA MOTORS AMERICA, INC.
  5. Complete the "G-Sensor Calibration" procedure.
