Repair procedures: Replacement

WARNING: This page is about a different car, the 2013 Hyundai Tucson and 2012 Hyundai Tucson. However, it is still accessible from the selected car via links, so may be relevant.
  1. Disconnect the negative (-) battery terminal.
  2. Disconnect the power mosfet connector (A) and then remove the power mosfet (B) after loosening the mounting screws.
    Fig 1: Identifying Power Mosfet Connector And Power Mosfet
    G06875510Courtesy of HYUNDAI MOTOR CO.
  3. Installation is the reverse order of removal.
