Repair procedures: Replacement

  1. Disconnect the negative (-) battery terminal.
  2. Remove the crash pad lower cover.

    (Refer to "LOWER PANEL REPLACEMENT ")

  3. Disconnect the power mosfet connector (A) and then remove the power mosfet (B) after loosening the mounting screws.
    Fig 1: Identifying Power Mosfet And Connector
    G08329636Courtesy of KIA MOTORS AMERICA, INC.
  4. Installation is the reverse order of removal.
