Repair procedures: Removal

  1. Remove the radiator upper cover(A) after loosening the mounting fasteners.
    Fig 1: Removing Radiator Upper Cover
    G00532315
  2. Remove the horn(B) after disconnecting the connector(A) and bolt.
    Fig 2: Identifying High Pitch Horn
    G08329002Courtesy of KIA MOTORS AMERICA, INC.
