Repair procedures: Removal

WARNING: This page is about a different variant/trim than selected.

Disconnect the negative (-) battery terminal.
Remove the driver airbag module.
(Refer to the AIRBAG HANDLING AND STORAGE )
Remove the steering wheel.
(Refer to the "STEERING COLUMN AND SHAFT ")
Remove the steering wheel cover (A) after loosening the screws.

Fig 1: Identifying Steering Wheel Cover And Mounting Screws
Courtesy of KIA MOTORS AMERICA, INC.
Remove the steering wheel remote control switch connector (A) after loosening the mounting screws.

Fig 2: Identifying Steering Wheel Remote Control Switch Connector Mounting Screws
Courtesy of KIA MOTORS AMERICA, INC.

[LH-Audio]

Fig 3: Identifying Steering Wheel Remote Control Switch Connector (LH-Audio)
Courtesy of KIA MOTORS AMERICA, INC.

[LH-Mute]

Fig 4: Identifying Steering Wheel Remote Control Switch Connector Mounting Screws (LH-Mute)
Courtesy of KIA MOTORS AMERICA, INC.

Fig 5: Identifying Steering Wheel Remote Control Switch Connector (LH-Mute)
Courtesy of KIA MOTORS AMERICA, INC.
