Power Circuit Inspection

IG "OFF" and disconnect Instrument cluster connector.
IG "ON" & ENG "OFF"
Measure voltage between terminal 5 of instrument cluster harness connector and chassis ground.
Specification: Approx. B+

Fig 1: Measuring Voltage Between Terminal 5 Of Instrument Cluster Harness Connector And Chassis Ground
Courtesy of KIA MOTORS AMERICA, INC.
Is the measured voltage within specification?
YES
- Go to "CONTROL CIRCUIT INSPECTION " procedure.
NO
- Check fuse between battery and instrument cluster for open or blown-off.
- Repair open or short to ground in harness, and go to "VERIFICATION OF VEHICLE REPAIR " procedure.
