Front Driveshaft Assembly: Installation

Installation is the reverse of removal.
CAUTION:
- Replace the circlip with new ones before the installation.
- Before the installation, apply the gear oil on the driveshaft splines (A) and contacting surface (B) of differential case oil seal.

  Fig 1: Installing Driveshaft To Differential Case
  Courtesy of KIA MOTORS AMERICA, INC.
CAUTION:
- Be sure to install both sides of the driveshaft.
- The washer (B) should be assembled with convex surface outward when installing the castle (A) nut and split pin (C).

  Fig 2: Identifying Castle, Washer And Split Pin
  Courtesy of KIA MOTORS AMERICA, INC.
