Rear Wiper Motor: Inspection: Notes

  1. Remove the connector from the rear wiper motor.
  2. Connect battery positive (+) and negative (-) cables to terminals 3 and 4 respectively.
  3. Check that the motor operates normally. Replace the motor if operates abnormally.
    Fig 1: Testing Rear Wiper Motor Operation
    G01954285Courtesy of KIA MOTORS AMERICA, INC.
