Component Inspection

  1. Ignition "OFF".
  2. Remove "TRANSAXLE RANGE SWITCH".
  3. Measure the resistance between each terminal of the sensor.

    Specification : Approx. 0 Ω

    Fig 1: Measuring Resistance Between Terminal Of Sensor
    G05186342Courtesy of KIA MOTORS AMERICA, INC.
  4. Is resistance within specifications?

    YES

    • Substitute with a known-good PCM/TCM and check for proper operation. If the problem is corrected, replace PCM/TCM as necessary and then go to "VERIFICATION OF VEHICLE REPAIR " procedure.

    NO
