Parts Location

WARNING: This page is about a different car, the 2006 Lexus IS 350 and 2006 Lexus IS 250. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Identifying Power Window Control System Part Location (1 Of 2)
G04049811Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Fig 2: Identifying Power Window Control System Part Location (2 Of 2)
G04049812Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
