IMS Power Seat Control
>>
MCU Connector Configuration
MCU Connector Configuration
Fig 1: MCU Connector Pinout
Courtesy of KIA MOTORS AMERICA, INC.
Courtesy of KIA MOTORS AMERICA, INC.
