Fuel Filler Cap

The fuel filler cap is equipped with a vacuum relief valve to prevent the escape of fuel vapor into the atmosphere.

Fig 1: Exploded View Of Fuel Filler Cap
G00319539Courtesy of KIA MOTORS AMERICA, INC.
