Clutch Master Cylinder: Removal

  1. Disconnect cable.
  2. Pull locktab, then remove fuse box.
  3. Remove spring clip and pin from master cylinder push rod.
  4. Remove master cylinder mounting nuts.
    NOTE: Clutch brake fluid will damage painted surfaces so use a container or shop towels for fluid collection. If fluid gets on a painted surface, rinse immediately with clear water to prevent damage.
    Fig 1: Illustrating Battery Cable
    G01078277Courtesy of KIA MOTORS AMERICA, INC.
  5. Disconnect clutch master cylinder hose.
  6. Disconnect clutch hydraulic line with SST (0K130 430 019).
  7. Remove clutch master cylinder.
