Home >> Kia >> 2003 >> Spectra Base, Automatic >> Repair and Diagnosis >> Suspension >> Rear Suspension >> Rear Cross Member >> Components

Rear Cross Member: Components

Fig 1: Illustrating Rear Cross Member Components

G01080626

Courtesy of KIA MOTORS AMERICA, INC.
