Ring Gear And Gear Case Assembly

Inspect ring gear for wear and cracks. If gear case is replaced, adjust bearing preload.

Fig 1: Inspecting Ring Gear For Wear And Cracks
G01078641Courtesy of KIA MOTORS AMERICA, INC.
