Blower Resistor: Inspection

WARNING: This page is about a different car, the 2005 Kia Spectra5, 2005 Kia Spectra, and 2004 Kia Spectra. However, it is still accessible from the selected car via links, so may be relevant.
  1. Measure terminal-to-terminal resistance of the blower resistor.
  2. If measured resistance is not within specification, the blower resistor must be replaced.
Fig 1: Testing Blower Resistor Resistance
G00333132Courtesy of KIA MOTORS AMERICA, INC.
Fig 2: Blower Resistor Resistance Chart
G00333133Courtesy of KIA MOTORS AMERICA, INC.
