Module-Trailer Tow C2 (Standard) Connector End View (D2399B)

Harness-Family: Body

Color: BLACK

Gender: FEMALE

Part Number: 33472-1206

Part Description: Not Available

Connector No: D2399B

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Trailer Tow C2 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Trailer Tow C2 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

L678

0.75

PARK LAMP FEED

BASE

L678

0.75

PARK LAMP FEED

BASE

L674

0.75

RIGHT REAR STOP/TURN SIGNAL FEED

N/A

L673

0.75

LEFT REAR STOP/TURN SIGNAL FEED

N/A

⁽¹⁾	Pins not listed are not used for this connector
