Module-Steering Column Control C4 (Standard) Connector End View (D3816D)

Harness-Family: Steering_Wheel

Color: BLACK

Gender: FEMALE

Part Number: 33401470

Part Description: Not Available

Connector No: D3816D

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Steering Column Control C4 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Steering Column Control C4 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Z998

0.35

GROUND

N/A

0.50

HORN SWITCH SENSE

N/A

A917

0.35

FUSED B(+)

N/A

T831

BN/VT

0.35

RETURN

N/A

T830

BN/OG

0.35

SIGNAL

N/A

D404

WH/BN

0.35

LIN BUS

N/A

D402

OG/VT

0.35

LIN BUS CBC 2

N/A

⁽¹⁾	Pins not listed are not used for this connector
