Module-Fuel Pump (Standard) Connector End View (D6602B)

Harness-Family: Body

Color: BLACK

Gender: FEMALE

Part Number: 33405994

Part Description: Not Available

Connector No: D6602B

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Fuel Pump Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Fuel Pump Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

G109

0.50

FUEL LEVEL SENSE RETURN

N/A

DB/WH

0.50

FUEL LEVEL SENSOR SIGNAL

N/A

N14

VT/BU

2.0

FUEL PUMP RETURN

N/A

N13

DB/OG

2.0

FUEL PUMP PWM CONTROL

N/A

⁽¹⁾	Pins not listed are not used for this connector
