Module-Body Control C3 (Standard) Connector End View (D2762C)

Harness-Family: Dash

Color: BLACK

Gender: FEMALE

Part Number: 15471053_15471039

Part Description: Not Available

Connector No: D2762C

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Body Control C3 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Body Control C3 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

F45

PK/OG

1.5

FUSED IGNITION SWITCH OUTPUT (START)

N/A

W10

1.0

FRONT WASHER PUMP MOTOR CONTROL

N/A

L42

BU/GY

0.50

RIGHT LOW BEAM DRIVER

EXCEPT HID HALOGEN

L44

WH/BG

0.35

RIGHT LOW BEAM DRIVER

LED

L47

BU/DB

0.50

LEFT HIGH BEAM DRIVER

EXCEPT HID HALOGEN

L33

WH/GN

0.35

HIGH BEAM FEED

LED

L48

BU/YE

0.50

RIGHT HIGH BEAM DRIVER

EXCEPT HID HALOGEN

L34

WH/GY

0.35

RIGHT HIGH BEAM DRIVER

LED

L89

WH/YE

1.0

LEFT FRONT FOG LAMP CONTROL

N/A

L90

WH/OG

1.0

RIGHT FRONT FOG LAMP CONTROL

N/A

F944

PK/GN

0.35

FUSED IGNITION

N/A

BN/WH

2.5

WIPER LOW SPEED CONTROL OUTPUT

N/A

BN/OG

2.5

WIPER HIGH SPEED CONTROL OUTPUT

N/A

L41

BU/BN

0.50

LEFT LOW BEAM DRIVER

EXCEPT HID HALOGEN

L43

WH/DB

0.35

LEFT LOW BEAM DRIVER

LED

W20

BN/YE

1.0

REAR WASHER PUMP MOTOR CONTROL

N/A

A910

1.0

FUSED B(+)

N/A

A910

0.75

FUSED B(+)

N/A

F949

PK/GN

0.75

FUSED IGNITION

N/A

F949

PK/GN

0.50

FUSED IGNITION

N/A

F944

PK/GN

0.35

FUSED IGNITION

N/A

F944

PK/GN

0.35

FUSED IGNITION

N/A

F741

PK/GN

1.0

FUSED IGNITION RUN/START

N/A

A905

1.5

FUSED B(+)

N/A

⁽¹⁾	Pins not listed are not used for this connector
