Fan-Radiator (Standard) Connector End View (D6632A)

Harness-Family: FRONT_END_MODULE

Color: BLACK

Gender: FEMALE

Part Number: 7289-5783-30

Part Description: Not Available

Connector No: D6632A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Fan-Radiator Connector End View (Standard)

GCWD1294455

Courtesy of CHRYSLER

Fig 2: Fan-Radiator Component Location (Standard)

GCWD1294464

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

A958

RD

10.0

FUSED B(+)

N/A

2

Z905

BK

10.0

GROUND

N/A

3

N29

DB/BU

0.75

RADIATOR FAN ENABLE SIGNAL

N/A

4

K173

BN/VT

0.75

LOW RAD FAN RELAY CONTROL

N/A

⁽¹⁾	Pins not listed are not used for this connector
