Display-Screen Center Stack C2 (Standard) Connector End View (D2996B)

Harness-Family: IP

Color: WHITE

Gender: FEMALE

Part Number: D4K10A-1D5A5-B

Part Description: Not Available

Connector No: D2996B

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Display-Screen Center Stack C2 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Display-Screen Center Stack C2 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

J107

0.82

VIDEO SIGNAL 1

N/A

⁽¹⁾	Pins not listed are not used for this connector
