Can Bus Splice Block 5 (Standard) Connector End View (D3201A)

Harness-Family: Body

Color: NATURAL

Gender: FEMALE

Part Number: 7187-8856_7388-0317-60

Part Description: Not Available

Connector No: D3201A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Can Bus Splice Block 5 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Can Bus Splice Block 5 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

D17

0.50

CAN IHS (+)

N/A

D17

0.50

CAN IHS (+)

N/A

D251

WH/OG

0.50

CAN IHS (+)

N/A

D191

BN/OG

0.50

CAN IHS (+)

N/A

D207

WH/GN

0.50

CAN IHS (+)

N/A

0.50

CAN CH (+)

N/A

0.50

CAN CH (+)

N/A

D77

0.50

CAN CH (+)

N/A

D18

WH/OG

0.50

CAN IHS (-)

N/A

D18

WH/OG

0.50

CAN IHS (-)

N/A

D250

0.50

CAN IHS (-)

N/A

D192

WH/OG

0.50

CAN IHS (-)

N/A

D206

0.50

CAN IHS (-)

N/A

0.50

CAN CH (-)

N/A

0.50

CAN CH (-)

N/A

D78

0.50

CAN CH (-)

N/A

⁽¹⁾	Pins not listed are not used for this connector
