Module-HVAC C2 (Standard) Connector End View (D3828B)

Harness-Family: IP

Color: BLACK

Gender: FEMALE

Part Number: 7283902830

Part Description: Not Available

Connector No: D3828B

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Hvac C2 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Hvac C2 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

C36

BU/BN

0.35

SNSR IN CAR TEMP SIG

N/A

C37

BU/OG

0.35

SNSR IN CAR TEMP RTN

N/A

⁽¹⁾	Pins not listed are not used for this connector
