Sensor-Humidity Rain Light (Standard) Connector End View (D3285A)

Harness-Family: Mirror_Int_Jumper

Color: BLACK

Gender: FEMALE

Part Number: 1-1718346-1

Part Description: Not Available

Connector No: D3285A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Sensor-Humidity Rain Light Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Sensor-Humidity Rain Light Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

A935

0.50

FUSED B(+)

N/A

D401

0.50

LIN BUS 1

N/A

Z930

0.50

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
