Module-Power-Blower Motor-Front C3 (Standard) Connector End View (D6608C)

Harness-Family: Blower_Jumper

Color: BLACK

Gender: FEMALE

Part Number: A.731.005.0.0

Part Description: Not Available

Connector No: D6608C

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Power-Blower Motor-Front C3 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Power-Blower Motor-Front C3 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

BLOWER MOTOR SUPPLY

N/A

Z134

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
